CONSMAC GW45 rebar bending and cutting machine is a professional-grade stationary tool engineered specifically for high‑volume reinforcement work in construction projects, including highways, bridges, residential buildings, and tunnel linings. Unlike handheld or portable benders, this bench‑type unit provides consistent bending accuracy and robust power for repeated heavy‑duty tasks, significantly reducing manual effort and improving daily output.

At the core of this machine is a 3KW pure copper induction motor running on 380V/50Hz three‑phase power, delivering reliable torque with low noise and minimal heat generation. The electric hydraulic control system ensures smooth, responsive operation, while the bending disc rotates at an adjustable speed of 3 to 15 revolutions per minute, allowing operators to match the pace to different bar diameters and bending angles. The machine accepts round steel bars from 6mm up to 50mm in diameter, with a maximum bending angle of 130 degrees (optional extension to 180 degrees available). It processes carbon steel, deformed rebar, and plain round bars with equal ease, making it versatile for various structural applications.

Structurally, the GW45 features a thick steel table plate and a reinforced frame that withstands continuous heavy use without deformation. The built‑in mechanical stopper system enables precise angle repetition, essential for producing uniform stirrups and shaped bars. For operator convenience, the machine includes a foot pedal for hands‑free control and a manual switch for fine adjustments, both designed with safety in mind. Heavy‑duty wheels are fitted to the base, allowing easy relocation between workstations or across job sites, while the compact footprint (880×740×850mm) saves valuable space in crowded workshops.

In terms of technical specifications, the GW45 offers a bending disc diameter of Φ345mm, a table thickness of 8mm (customizable), and a total weight of approximately 350kg. The machine is available in multiple voltage configurations (220V or 380V, 50/60Hz) to suit global markets. Core components such as the motor, gearbox, and hydraulic system are backed by a one‑year warranty, ensuring long‑term reliability and low maintenance costs. Each unit is packaged in a sturdy metal box or wooden crate, suitable for safe container shipping.

This machine is widely used in retail construction supplies, on‑site concrete reinforcement, and prefabrication yards. Its combination of power, precision, and portability makes the GW45 a trusted partner for contractors and fabricators who demand consistent performance under tough conditions. With proper care, this machine delivers years of dependable service, significantly boosting productivity and reducing labor costs on every project.
